It is used to attach the chimney to the wall or ceiling
Clamp diameter is selected according to the diameter of the pipe which is fixed
Standard length adjustment range: 0 - 100 mm; 0 - 200 mm; 0 - 300 mm; 0 - 400 mm; 0 - 500 mm
| D, mm | H, mm | S, mm | B, mm |
| 360 | 30 | 2 | 12 |
| 420 | 50 | 2 | 18 |
| 460 | 50 | 2 | 18 |
| 520 | 50 | 2 | 18 |
| 560 | 50 | 2 | 18 |
| 620 | 50 | 3 | 18 |
| 660 | 50 | 3 | 18 |
| 720 | 70 | 3 | 22 |
| 760 | 70 | 3 | 22 |
| 820 | 70 | 3 | 22 |
| 860 | 70 | 3 | 22 |
| 960 | 70 | 3 | 22 |
| 1060 | 70 | 3 | 22 |
